posted this note on and tagged it with Narrating my work ΠiFi Music Player

The second attempt at 3D printing a base plate for the πFi went much better but there’s still plenty of room for improvements. Currently I’m testing out sizes for the QR cards and how those sizes effects the necessary distance between the cards and the camera, which in turn effects how large the whole device will need to be. Currently I’m leaning toward a 7,0×8,5 cm large card with a 5,5×5,5 cm QR code centered on the card and this means that the full enclosure doesn’t need to be any bigger in the base than the Pi itself is.

If stand for the QR cards are on top of the USB och Ethernet ports with just a couple of mm of plastic between them, the camera sensor need to be about 55 mm above the surface of the Pi.

Tidbits

If I connect a display to the Pi I can use raspivid to display the output of the camera on that display. The display needs to be connected to the Pi but the command itself can be run either locally on the Pi or remotely via SSH.

For example: raspivid -o video.h264 -t 180000 -w 640 -h 480 will display an image for three minutes, showing the same that the QR Reader script will see.

∞
posted this note on and tagged it with 3D printing Narrating my work ΠiFi Music Player

Turns out there where multiple problems with yesterdays attempt at a base plate for the πFi.1 I had the measurements for the QR cards completely wrong, so even if the Pi had fit it wouldn’t have worked.

This morning I drew up a quick 2D sketch in OmniGraffle and then I worked from that one to get the 3D version in Fusion. Hopefully this one will work better. The printer says about six hours to print.

  1. Note to self: Make up my mind whether it’s πiFi or πfi. ↩
∞
posted this note on and tagged it with 3D printing Narrating my work The Year of Music ΠiFi Music Player

I’m changing things up for the πiFi Music Player.

The way I intended to make the πiFi I would need to do most, if not all of these and it just makes it too large of a project. So I’ve scaled it back. At it’s core it is still going to work the same way but instead of having a built in power amp and connecting it to custom built passive speakers I’m going to make a device that gives line level audio out and connect it to a pair of powered speakers that Iris already have but rarely use.

Raspberry Pi Zero with a JustBook DAC Zero

At first I decided to do this using a Raspberry Pi Zero and a JustBook DAC Zero and that was what I sat down to work on tonight. Unfortunately I realised that the Pi Camera Module needs a different cable to be compatible with the Zero and none of my usual suppliers for these kinds of things have that cable in stock. As I was thinking about whether to keep working on other parts of it hit me, why not use the Pi 3 that I used before but without the power amplifier hat? It has a line out built in and works with the camera cable that I have?

So tonight I’ve been working on the first iteration of a simple 3D printed base plate to mount the Pi on, with place to stick the QR codes on in front of it and a mount for the camera. So far the camera mount isn’t finished but I do have a prototype sketch that should work for mounting the Pi and the QR codes. I’ll try to get it printed tomorrow.

A screen shot from Fusion 360 and my sketch of the base plate.
∞
posted this note on


This photo was taken six years ago, almost to the minute, right after we came home with our daughter for the first time.

Happy birthday Iris!

∞

Replies and comments

posted this note on and tagged it with The Year of Music

My yearly theme for 2021 will be The Year of Music. I was going to write more about this tonight but I ended up playing music instead. I consider that a win.

I’ll write more about the theme and what I want to do with it another day.

∞
posted this note on and tagged it with Narrating my work ΠiFi Music Player

Even though my work concerns pro audio a lot, the Thiele-Small Parameters are something I’m more or less not familiar with at all. But if I read this guide and the specs for the drivers I intend to use for the πiFi Music Player, this means I need to build a completely sealed enclosure with a volume of at least 1,8 liters.

All right than…

∞
posted this note on and tagged it with Narrating my work ΠiFi Music Player

Apparently I haven’t blogged about, and therefore not really done anything about, the πiFi Music Player for over a year. I’m changing that right now.

∞
